CHARTU CH-AT0808 Matrix Switcher

Buy CHARTU CH-AT0808 Matrix Switcher

Supported Input Card/Channel: 2/8 HDMI | Bandwith: 13.5 Gbps based exchange processing speed | Supported Output Card/Channel: 2/8 DVI
Only 1 left in stock
On request
  • Pengiriman cepat
    Kami menawarkan pengiriman domestik dan internasional melalui semua ekspedisi pengiriman terbaik.
  • Pembayaran aman
    Kami menerima semua pembayaran melalu kartu debit/kredit dan pembayaran lainnya..
  • Kontak kami
    Anda dapat mengambil pesanan secara langsung di salah satu toko kami. Hubungi kami untuk lebih jelasnya!
BrandCHARTU
SKUO02.P03.A01.P01.00002
Fitur
  • HDMI Input Port : 8
  • DVI Output Port : 8
Spesifikasi
  • Supported Input Card/Channel: 2/8 HDMI
  • Bandwith: 13.5 Gbps based exchange processing speed
  • Supported Output Card/Channel: 2/8 DVI
  • Ultra HD background image display
  • Hardware-based signal processing, no operating system, not requiring Antivirus
  • Visual management applications, support Windows OS
  • Control Slot: 1
  • Power slot: 1, support redundant power supplies for models above 3636 chassis
  • Supported Input Card: DVI, HDMI, FIBER, SDI, IP Network Input, CAT5, DU-DVI
  • Supported Splicing Output Card: STDVI4, STDVI2, STCAT4, STCAT2, STFB4, STFB
  • Splicing: 4 output card can support 2 windows overlapping, 2 output card can support 4 windows overlapping
  • Supported Control Card: CON
  • Protocol and Baudrate: Baudrate: 9600,Data Bit: 8 bit,Stop Bit: 1,No parity check bit
  • Keyboard Control Interface/Protocol: 4 Pin Phoenix Socket/RS485
  • Serial Control Interface/Protocol: 9 Pin D-Sub Socket/RS232
  • Ethernet Control Interface/Protocol: RJ45/TCP/Ip
  • Generic Specification :
  • Power Supply: 100VAC ~ 240VAC,50/60 Hz, National Standard Self-adaptive power supply
  • Server rack dimension: 2U
  • MTBF: 30.000 hrs
Garansi produk1 Tahun
